Rbsic / SiSiC Beam High Temperature Resistance For Electric Porcelain Industry

Brand Name : BD

Model Number : as per customer need

Certification : ISO9001

Place of Origin : China

MOQ : 30pcs

Price : price discussion

Payment Terms : TT

Supply Ability : 5000PCS/MONTH

Delivery Time : 20days

Packaging Details : standard woodern case

Density : >3.02g/cm3

open porosity : <0.1

Thermal Conductivity : 45(1200℃)

Straightness : 1‰

name : silicon carbide beams

Contact Now

high temperature resistance Rbsic/SiSiC beam used to sanitary wares

SISIC Cross Beams is suitable for bearing structure beam in tunnel kiln, shuttle kiln and other industrial furnaces. It has the advantages of high temperature bearing capacity, good thermal conductivity, long service life, no bending deformation, long service life, etc. IT is an ideal kiln for sanitary porcelain and electric porcelain industry.

Rbsic / SiSiC Beam High Temperature Resistance For Electric Porcelain Industry

Bearing Capacity SISIC(RBSIC)Beam
Sectional Dimension(mm)		Thickness(mm)	Concentrated Loading (kg.m/L)		Uniformly Distributed Loading (kg.m/L)
B Side	S Side	Thickness(mm)	B Side	S Side	B Side	S Side
30	30	5	74	74	147	147
30	40	5	117	95	235	190
40	40	5	149	149	298	298
50	50	6	283	283	567	567
50	60	6	374	331	748	662
50	70	6	473	379	946	757
60	60	7	481	481	962	965
80	80	7	935	935	1869	1869
100	100	8	1708	1708	3416	3416
110	110	10	2498	2498	4997	4997

Concentrated Loading=the Value in The Table x1/L. Uniformly Distribute Loading= The Value in the Table Accordingly x 1/L.

The temperature is 1380℃
